| RFID Features | Model | RC5135 |
| Frequency | 860-960 MHz | |
| Chip Type | NXP Ucode 9xm | |
| Memory | 3 Customer Configurable Memory ① User - 752 bits; EPC - 128 bits; TID - 96 bits ② User - 624bits; EPC - 256 bits; TID - 96 bits ③ User - 384 bits; EPC - 496 bits; TID - 96 bits |
|
| Data Storage | > 20 years | |
| Re-write | 100,000 times | |
| Read Range(2W ERP) | FCC: > 7.0 m, on cardboard; > 5.0 m, on PTFE ETSI: > 7.0 m, on cardboard; > 9.0 m on PTFE |
|
| Physical Features | Dimensions | 41 x 10 mm / 1.61 x 0.39 in |
| Material | Coated Paper | |
| Adhesive | 3M99786 | |
| Operating Temperature | -40°C to 85°C / -40°F to 185°F | |
| Storage Condition | 150°C/1 hour,134°C/2 hour 50±10% RH, Store away from sunlight |
|
| Other Features | Installation | Adhesive on clean & dry surface |
| Customization | Printing, Encoding, Designing, etc. | |
| Package | 2,500 pcs / roll, 4 rolls / box | |
| Application | Medical consumable / Manufacturing industry |
