| RFID Features | Model | RCO7040 |
| Air Interface Protocol | EPC Class 1 Gen 2 / ISO 18000-63 Type C | |
| Frequency | 860-960 MHz | |
| Chip Type | Alien Higgs 9 | |
| Memory | User - 688 bits; EPC - 96 bits(up to 496 bits); TID - 96 bits | |
| Data Storage | > 100 years | |
| Re-write | 100,000 times | |
| Read Range(2W ERP) | FCC: > 9.6 m(31.5 ft), on metal | |
| Physical Features | Dimensions | 70 x 30 x 1 mm / 2.75 x 1.18 x 0.04 in |
| Face Material | White PET | |
| Operating Temperature | -40°C to 85°C / -40°F to 185°F | |
| Survival Temperature | -40°C to 120°C / -40°F to 248°F | |
| Storage Condition | 20±5℃, 50±10% RH, Store away from sunlight | |
| IP Rate | IP68, test for 5 hours at 1m deep water | |
| Other Features | Installation | Adhesive on clean & dry surface |
| Customization | Printing, Encoding, Designing, etc. | |
| Recommended Ribbon | Resin-based | |
| Package | 500 pcs / roll, 4 rolls / box | |
| Application | Facility & equipment / Fixed asset Electronics / Liquid container / Metal parts |
