| RFID Features | Model | RCO7017 |
| Air Interface Protocol | EPC Class 1 Gen 2 / ISO 18000-63 Type C | |
| Frequency | 860-960 MHz | |
| Chip Type | Impinj Monza R6P | |
| Memory | User - 32(64) bits; EPC - 128(96) bits; TID - 96 bits | |
| Data Storage | > 100 years | |
| Re-write | 100,000 times | |
| Read Range(2W ERP) | FCC: > 7.0 m(22.3 ft), on metal | |
| Physical Features | Dimensions | 100 x 40 x 1 mm / 3.94 x 1.57 x 0.04 in |
| Face Material | White PET | |
| Operating Temperature | -40°C to 85°C / -40°F to 185°F | |
| Survival Temperature | -40°C to 120°C / -40°F to 248°F | |
| Storage Condition | 20±5℃, 50±10% RH, Store away from sunlight | |
| IP Rate | IP68, test for 5 hours at 1m deep water | |
| Other Features | Installation | Adhesive on clean & dry surface |
| Customization | Printing, Encoding, Designing, etc. | |
| Recommended Ribbon | Resin-based | |
| Package | 300 pcs / roll, 4 rolls / box | |
| Application | Facility & equipment / Fixed asset Electronics / Liquid container / Metal parts |
