| Physical Features | Model | Duo LA604 |
| Material | Polyester | |
| Length x Width | 50 x 20 mm (1.97 x 0.79 in) | |
| Thickness | 1.8 mm(0.07 in) on chip location only, Rest of tag is 0.75 mm(0.03 in) |
|
| Weight | 0.5 g | |
| RFID Features: | RFID Standard | UHF:ISO\IEC 18000-6C, EPC Global GEN2 V2.0 HF: ISO\IEC 15693 TYPE A; NFC: FORUM TYPE 5 |
| Frequency | 860-960 MHZ & 13.56MHz（worldwide） | |
| Chip Type | EM4425 | |
| Memory | UID-64 bits, TID- 96 bits 2048-bits used for HF +UHF USER memory |
|
| Data Storage | > 15 years | |
| Re-write | 100,000 times | |
| Read Range(Fixed Reader) | FCC: > 2.3 m (7.6 ft) ETSI: > 2.2 m (7.25 ft) |
|
| Read Range(Handheld Reader) | UHF - 6.0 m | |
| Read Range(HF Desktop Reader) | HF - 4.0 cm(13.56 MHz) | |
| Other Features: | Installation | Three-side stitching or pouch |
| Warranty | 200 washing cycles or 3 years, whichever comes first | |
| Washing Method | Laundry, Dry cleaning | |
| Water Extraction pressure | 60 bars | |
| Chemical Resistance | Detergent, Softener, Bleach (Oxygen/ Chlorine), Alkali | |
| Washing Temperature | 90°C (194°F)/15 minutes | |
| Pre-drying in Tumble | 180°C (356°F)/30 minutes | |
| Ironing Tempereature | 185°C (365°F)/10 seconds | |
| Sterilization Tempereature | 135°℃ (275°F)/20 minutes | |
| Humidity/ Temperature-Operating | -20~+85℃（-4~185℉）/ 8-95%RH | |
| Customization | Printing, Encoding, Design, etc. | |
| Package | 1000 pcs / bag, 10 bag / box | |
| Applications | Industrial washing/Management of uniforms Medical apparel management/Military clothing management |
