| RFID Features | Model | RC5020 |
| Frequency | 860-960 MHz | |
| Chip Type | NXP Ucode 9xe | |
| Memory | User - N/A; EPC - 128 bits; TID - 96 bits | |
| Data Storage | > 10 years | |
| Re-write | 100,000 times | |
| Read Range(2W ERP) | FCC: > 1.6 m(5.3 ft), on liquid ETSI:> 1.2 m(3.9 ft), on liquid |
|
| Physical Features | Dimensions | 43 x 18 mm / 1.69 x 0.71 in |
| Material | PET | |
| Adhesive | Double-sided tape | |
| Operating Temperature | -40°C to 85°C / -40°F to 185°F | |
| Storage Condition | 20±5℃, 50±10% RH, Store away from sunlight | |
| Other Features | Installation | Adhesive on clean & dry surface |
| Customization | Encoding, Designing, etc. | |
| Package | 2,500 pcs / roll, 4 rolls / box | |
| Application | Alcohol & Beverage / Medicine & vaccine Cosmetic & perfume / Detergent & reagent |
