| RFID Features | Model | RC5063 |
| Frequency | 860-960 MHz | |
| Chip Type | Alien Higgs 10 | |
| Memory | Up to 128 EPC bits (nominally 96 bits) Up to 32 User bits (with 96 bit EPC) |
|
| Data Storage | > 10 years | |
| Re-write | 100,000 times | |
| Read Range(2W ERP) | FCC: > 9.0 m, on cardboard; > 7.5 m, on PTFE ETSI: > 9.0 m, on cardboard; > 9.0 m on PTFE |
|
| Physical Features | Dimensions | 54 x 35 mm / 2.13 x 1.38 in |
| Material | Coated Paper | |
| Adhesive | Hot Melt | |
| Operating Temperature | -40°C to 85°C / -40°F to 185°F | |
| Storage Condition | 20±5℃, 50±10% RH, Store away from sunlight | |
| Other Features | Installation | Adhesive on clean & dry surface |
| Customization | Printing, Encoding, Designing, etc. | |
| Package | 2,500 pcs / roll, 4 rolls / box | |
| Application | Alcohol & Beverage / Medicine & vaccine Cosmetic & perfume / Detergent & reagent |
