RFID Features Model RCO7050
Air Interface Protocol EPC Class 1 Gen 2 / ISO 18000-63 Type C
Frequency 860-960 MHz
Chip Type NXP Ucode 8
Memory User - N/A; EPC - 128 bits; TID - 96 bits
Data Storage > 100 years
Re-write 100,000 times
Read Range(2W ERP) FCC: > 9.5 m(31.2 ft) , on metal
ETSI: > 10.0 m(32.8 ft) , on metal
Physical Features Dimensions 95 x 22 x 1.25 mm / 3.74 x 0.87 x 0.05 in
Face Material White PET
Operating Temperature -40°C to 85°C / -40°F to 185°F
Survival Temperature -40°C to 120°C / -40°F to 248°F
Storage Condition 20±5℃, 50±10% RH, Store away from sunlight
IP Rate IP68, test for 5 hours at 1m deep water
Other Features Installation Adhesive on clean & dry surface
Customization Printing, Encoding, Designing, etc.
Recommended Ribbon Resin-based
Package 500 pcs / roll, 4 rolls / box
Application Facility & equipment / Fixed asset
Electronics / Liquid container / Metal parts
