| RFID Features | Mdoel | RCP8005 |
| Air Interface Protocol | EPC Class 1 Gen 2 / ISO 18000-63 Type C | |
| Frequency | 860-960 MHz | |
| Chip Type | NXP Ucode 8 | |
| Memory | User - N/A; EPC - 128 bits; TID - 96 bits | |
| Data Storage | > 10 years | |
| Re-write | 100,000 times | |
| Read Range(2W ERP) | FCC: > 7.7 m(25.3 ft) , on metal ETSI: > 6.8 m(22.3 ft) , on metal |
|
| Physical Features | Dimension | 36 x 13 x 3 mm / 1.42 x 0.51 x 0.12 in |
| Material | FR-4 | |
| Weight | 2.8 g | |
| Color | Black | |
| Operating Temperature | -40°C to 85°C / -40°F to 185°F | |
| Survival Temperature | -40°C to 150°C / -40°F to 302°F | |
| Storage Condition | 20±5℃, 50±10% RH, Store away from sunlight | |
| IP Rate | IP68, test for 5 hours at 1m deep water | |
| Other Features | Installation | Adhesive(clean and dry surface), Rivet, Magnet, Screw |
| Customization | Printing, Encoding, Design, etc. | |
| Package | 200 pcs / bag, 10 bags / box | |
| Application | Electricity and railway management | Industry automation management Metallic Asset management | Shelf and tower management,etc |
