| Physical Features | Model | RCT10002 |
| Material | FR-4 | |
| Color | Green | |
| Dimensions | 58 x 1 x 1.3 mm(L x H x W) | |
| Weight | 0.3 g | |
| Working Temp | -40~+85℃ | |
| Survive Temp | -40~+150℃ | |
| IP Code | IP68 | |
| Humidity | 98% Non-condensing | |
| RFID Features | RFID Standard | EPC C1G2 (ISO18000-6C) |
| Chip Type | Impinj Monza 4QT | |
| Memory | User-512 bits; EPC-128 bits; TID-48 bits | |
| Read Range(Fixed Reader) | 5.8 m, on cardboard; 4.8 m, in air | |
| Read Range(Handheld Reader) | 2.5 m, on cardboard; 1.5 m, in air | |
| Other Features | Data Storage | > 10 years |
| Re-write | 100000 times | |
| Installation | 3M adhesive, Rivet, Magnet, Screw | |
| Customization | Printing LOGO, Barcode, Serial number, Encoding, Designing,etc | |
| Application |
Wooden pallet identification | Plastic pallet tracking Non-metal assets management | High temperature asset tracking,etc |
